Khoom Description

Lub tshuab tsis siv neeg ntoo pallet thaiv kev sib txuas tshuab muaj xws li thaiv qhov chaw thau khoom khib nyiab, lub lawj board loading khib, thiab lub tshuab ntsia hlau. Cov neeg khiav dej num manually tso cov blocks thiab lawj boards rau lawv cov racks; lub tshuab ces cia li pub thiab conveys cov ntaub ntawv mus rau nailing chaw nres tsheb rau automated los ua ke. Nrog phau ntawv thauj khoom ua raws li kev ua haujlwm nailing thiab tso zis, lub kaw lus txo qis kev ua haujlwm thiab txhawb nqa ntau lawm.

wood pallet block connecting machine

Khoom Parameter

Cov txheej txheem loj	800-1300 hli
Industrial tswj hom	Siemens
Nail phom brand	Stanley Bostitch 70 ntsia thawv phom (USA) * 3
Cua siab	0.8MPA
Ntsia phom ceev	4-8 vib nas this / stroke
Lub cev muaj zog	1.2KW servo lub cev muaj zog
Tswj hom	Siemens industrial tswj
Kev siv hluav taws xob	220V voltage
Hom kev ua haujlwm	Kov npo ua haujlwm
Hom kev tsim khoom	Phau ntawv pub / Tsis siv neeg ntsia thawv
Cov khoom siv qhov ntev	2400 * 2200 * 2100 hli

Cov khoom siv

Tsis siv neeg ntoo pallet thaiv kev sib txuas tshuab tuaj yeemua hauj lwm ua ke nrog tsis siv neeg pallet nailing tshuab. Nws yog qhov tsim nyog rau thaiv -style pallets- xws li Euro pallets, CP pallets, thiab hnub ci PV pallets - ntawm lwm tus.
Qhov no tsis siv neeg ntoo pallet thaiv kev sib txuas tshuab tuaj yeem sib koom ua ke boards ntawm qhov sib txawv ntawm qhov ntev, haum rau cov laug cam xws li 800 hli txog 1300 hli. Nws kuj muaj ntau yam hais txog tus ntsia thawv specifications, txhawb ntau qhov ntau thiab tsawg thiab hom-xws li du -shank thiab nplhaib-shank rau tes.

wood pallet block connecting machine

Khoom Feature

1. High Output: Ntau lawm ceev yog tsib zaug sai dua li phau ntawv nailing, nws tsuas yog siv li 4 mus rau 8 vib nas this los siv cov ntsia hlau tsis siv neeg ua kom tiav txhua lub voj voog.
2. Cov Txheej Txheem Ua Haujlwm Zoo: Tsis siv neeg pub khoom noj, automated nailing, thiab tsis siv neeg tiav - cov khoom tso tawm.
3. Precise Nailing: Ua kom cov ntsia hlau zoo ib yam, ua rau cov khoom zoo nkauj zoo nkauj.
4. Siemens Control System: Tsim los ntawm Siemens tswj qhov system kom paub tseeb tias qhov yuam kev - ua haujlwm dawb.
5. Cov Khoom Siv Tshwj Xeeb: Cov ntoo pallet thaiv lub tshuab txuas nrog peb lub Stanley Bostitch 70-series ntsia thawv phom (USA-ua), ua kom zoo thiab txhim khu kev qha.
6. Touchscreen Interface: Tus neeg siv- tus phooj ywg touchscreen interface uas tso cai rau kev ua haujlwm yooj yim, yooj yim thiab meej qhov kev hloov pauv.

7. Advanced Automation: Ua tsaug rau nws cov CNC tswj qhov system-paired nrog 1.2 kW servo lub cev muaj zog thiab precision reducer- ntoo pallet thaiv kev sib txuas tshuab ua haujlwm nrog xoom yuam kev kam rau ua. Nws yog programmed kom tsis txhob ua haujlwm thaum muaj cov khoom jam lossis tus ntsia thawv - teeb meem noj.
8. Txhim Kho Kev Nyab Xeeb: Lub chaw tswj xyuas tus neeg teb xov tooj tau muab tso rau qhov chaw nyab xeeb ntawm thaj chaw ua haujlwm ntsia hlau, ua kom muaj kev nyab xeeb dua rau cov neeg ua haujlwm.

wood pallet block connecting machine
